Introduction
Zeolite CU-ZSM-5 catalyst is a metal-modified molecular sieve catalytic material formed by introducing copper species (Cu⁺ / Cu²⁺ / CuOₓ) through ion exchange or loading, using ZSM-5 molecular sieve as a support. The introduction of Cu species does not change the framework of ZSM-5, so CU-ZSM-5 also has a MFI structure.
Products Description
Core Advantage
The core advantage of CU-ZSM-5 lies in its oxidation-reduction catalytic function. Cu species are highly dispersed within the channels, which is the fundamental reason for its redox catalytic ability.
Structural Feature
CU-ZSM-5 zeolite catalyst has a ten-membered ring three-dimensional cross-porous structure, its straight pore diameter is 0.53nm × 0.56nm, and the serrated pore diameter is 0.51nm × 0.55nm. It is a mesoporous molecular sieve, with confined pores, thus exhibiting good selectivity.
Hydrothermal Stability
CU-ZSM-5 zeolite exhibits excellent hydrothermal stability, can be synergistically catalyzed with acidic substances.
Hot Tags: zeolite catalyst cu-zsm-5, China zeolite catalyst cu-zsm-5 manufacturers, suppliers
Technical Specification
|
Type |
CU-ZSM-5 |
|
Apprearance |
Light blue powder |
|
Crystal Structure |
MFI |
|
Crystal Size(μm) |
2~6 |
|
BET Surface Area(m2/g) |
>380 |
|
SiO2/Al2O3(mol/mol) |
20~80 |
|
Crystallinity(%) |
>95 |
Application
- NH3-SCR Denitrification
- NOx Decomposition
